GS3101 XPON Modem

KGD IC Xtal:1 DDR3 init. DRAMC init done. Calculate size. DRAM size=256MB Set new TRFC. ddr-800 7512DRAMC V1.2.2 (0) EN751221 at Sat Jan 11 17:36:11 CST 2020 version 1.1 free bootbase Memory size 256MB Set SPI Clock to 50 Mhz spi_nand_probe: mfr_id=0x98, dev_id=0xcb Using Flash ECC. Detected SPI NAND Flash : _SPI_NAND_DEVICE_ID_TC58CVG1S3H, Flash Size=0x10000000 bmt pool size: 163 BMT & BBT Init Success Not found TC Phy Not found TC Phy Not found TC Phy Not found TC Phy Press any key in 3 secs to enter boot command mode. ............................................................ test==>0,80000,1000000 ! ==> boot flag = 0, 190000! Decompress to 80002000 free_mem_ptr=80950000 free_mem_ptr_end=807B0000 from main Uncompressing [LZMA] ... done. Initializing cgroup subsys cpu Linux version 2.6.36 (root@debian) (gcc version 4.6.3 (Buildroot 2015.08.1) ) #26 SMP Thu Mar 7 17:44:08 CST 2019 ISPRAM0: PA=00390000,Size=00010000,enabled memsize:256MB EcoNet EN751221 SOC prom init bootconsole [early0] enabled CPU revision is: 00019558 (MIPS 34Kc) Determined physical RAM map: memory: 0ffe0000 @ 00020000 (usable) Wasting 1024 bytes for tracking 32 unused pages Zone PFN ranges: Normal 0x00000020 -> 0x00010000 Movable zone start PFN for each node early_node_map[1] active PFN ranges 0: 0x00000020 -> 0x00010000 3 available secondary CPU TC(s) PERCPU: Embedded 7 pages/cpu @81203000 s7264 r8192 d13216 u65536 pcpu-alloc: s7264 r8192 d13216 u65536 alloc=16*4096 pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3 Built 1 zonelists in Zone order, mobility grouping on. Total pages: 64992 Kernel command line: es=1 PID hash table entries: 1024 (order: 0, 4096 bytes) Dentry cache hash table entries: 32768 (order: 5, 131072 bytes) Inode-cache hash table entries: 16384 (order: 4, 65536 bytes) Primary instruction cache 64kB, VIPT, 4-way, linesize 32 bytes. Primary data cache 32kB, 4-way, VIPT, cache aliases, linesize 32 bytes Writing ErrCtl register=0002ab8f Readback ErrCtl register=0002ab8f nmi base is 81274200 allocated 1310080 bytes of page_cgroup please try 'cgroup_disable=memory' option if you don't want memory cgroups Memory: 253404k/262016k available (3704k kernel code, 8612k reserved, 844k data, 220k init, 0k highmem) SLUB: Genslabs=7, HWalign=32, Order=0-3, MinObjects=0, CPUs=4, Nodes=1 Hierarchical RCU implementation. RCU-based detection of stalled CPUs is disabled. Verbose stalled-CPUs detection is disabled. NR_IRQS:64 CPU frequency 900.00 MHz Using 199.996 MHz high precision timer. console [ttyS0] enabled, bootconsole disabled console [ttyS0] enabled, bootconsole disabled Calibrating delay loop... 598.01 BogoMIPS (lpj=2990080) pid_max: default: 32768 minimum: 301 Mount-cache hash table entries: 512 Initializing cgroup subsys memory 34K sync es set to 1. Config7: 0x80080500 Limit of 4 TCs set TLB of 64 entry pairs shared by 2 VPEs VPE 0: TC 0 1 2, VPE 1: TC 3 IPI buffer pool of 16 buffers CPU revision is: 00019558 ((null)) TC 1 going on-line as CPU 1 CPU revision is: 00019558 ((null)) TC 2 going on-line as CPU 2 CPU revision is: 00019558 ((null)) TC 3 going on-line as CPU 3 Brought up 4 CPUs NET: Registered protocol family 16 FailSta_net_link: create netlink socket ok. PCIe driver version: 751221.5.20170807 MT7512_pcie_init check pcie link up status: isRC0_LINKUP=1 isRC1_LINKUP=0 registering PCI controller with io_map_base unset Initializing Ecnt Event Netlink Socket Initializing Econet Event Netlink Socket nl_sk = 8fcb6000 bio: create slab <bio-0> at 0 usbcore: registered new interface driver usbfs usbcore: registered new interface driver hub usbcore: registered new device driver usb pci 0000:00:01.0: unknown header type 2d, ignoring device pci 0000:00:00.0: BAR 8: assigned [mem 0x20000000-0x200fffff] pci 0000:01:00.0: BAR 0: assigned [mem 0x20000000-0x200fffff] pci 0000:01:00.0: BAR 0: set to [mem 0x20000000-0x200fffff] (PCI address [0x20000000-0x200fffff] pci 0000:00:00.0: PCI bridge to [bus 01-01] pci 0000:00:00.0: bridge window [io disabled] pci 0000:00:00.0: bridge window [mem 0x20000000-0x200fffff] pci 0000:00:00.0: bridge window [mem pref disabled] PCI: Enabling device 0000:00:00.0 (0000 -> 0002) NET: Registered protocol family 8 NET: Registered protocol family 20 Switching to clocksource MIPS NET: Registered protocol family 2 IP route cache hash table entries: 2048 (order: 1, 8192 bytes) TCP established hash table entries: 8192 (order: 4, 65536 bytes) TCP bind hash table entries: 8192 (order: 4, 65536 bytes) TCP: Hash tables configured (established 8192 bind 8192) TCP reno registered UDP hash table entries: 128 (order: 0, 4096 bytes) UDP-Lite hash table entries: 128 (order: 0, 4096 bytes) NET: Registered protocol family 1 mt7512_pcie_fixup: 0x1438 = 20000014 TC3162 hardware watchdog module loaded. squashfs: version 4.0 (2009/01/31) Phillip Lougher NTFS driver 2.1.29 [Flags: R/W DEBUG]. JFFS2 version 2.2 (NAND) (ZLIB) (RTIME) (c) 2001-2006 Red Hat, Inc. msgmni has been set to 494 cryptomgr_test used greatest stack depth: 15616 bytes left io scheduler noop registered (default) ttyS0 at I/O 0xbfbf0003 (irq = 1) is a TC3162 ECNT ring buffer init success brd: module loaded SPI Flash Init Start Found no SPI flash device IS_SPIFLASH=0x0, IS_NANDFLASH=0x2, (0xBFA10114)=0x6) Set SPI Clock to 50 Mhz SPI_NAND_Flash_init: before init, mtx_mode_tog=0xl9, manaul_en=0x1 spi_nand_probe: mfr_id=0x98, dev_id=0xcb Detected SPI NAND Flash : _SPI_NAND_DEVICE_ID_TC58CVG1S3H, Flash Size=0x10000000 spi nand flash tc3162: flash device 0x01000000 at 0x1c000000 EN7512 mtd init: spi nand probe enter [spi_nand_setup] : Enter NAND device: Manufacturer ID: 0x98, Chip ID: 0xcb (Toshiba _SPI_NAND_DEVICE_ID_TC58CVG1S3H) nand_scan_ident ok [spi_nand_setup]: chip size = 0x10000000, erase_shift=0x11 calc_bmt_pool_size : need_valid_block_num=0xa3, total_block=0x800 bmt pool size: 163 BMT & BBT Init Success parsing <0[bootloader],0[romfile],16m[tclinux],16m[tclinux_slave],34m[java],96m[yaffs]> partition 9: name <yaffs>, offset ffffffff, size 6000000, mask flags 0 partition 8: name <java>, offset ffffffff, size 2200000, mask flags 0 partition 7: name <tclinux_slave>, offset ffffffff, size 1000000, mask flags 0 partition 4: name <tclinux>, offset ffffffff, size 1000000, mask flags 0 partition 1: name <romfile>, offset ffffffff, size fffffffe, mask flags 0 partition 0: name <bootloader>, offset ffffffff, size fffffffe, mask flags 0 tclinux_slave partition size = 1000000, real size = 1000000fe tclinux_slave partition size < its real size!!! Creating 11 MTD partitions on "EN7512-SPI_NAND": 0x000000000000-0x000000040000 : "bootloader" 0x000000040000-0x000000080000 : "romfile" 0x000000080000-0x00000020f5c8 : "kernel" mtd: partition "kernel" doesn't end on an erase block -- force read-only 0x00000020f5c8-0x000000f5f5c8 : "rootfs" mtd: partition "rootfs" doesn't start on an erase block boundary -- force read-only 0x000000080000-0x000001080000 : "tclinux" 0x000001080000-0x0000010800ff : "kernel_slave" mtd: partition "kernel_slave" doesn't end on an erase block -- force read-only 0x0000010800ff-0x00000e000000 : "rootfs_slave" mtd: partition "rootfs_slave" doesn't start on an erase block boundary -- force read-only 0x000001080000-0x000002080000 : "tclinux_slave" 0x000002080000-0x000004280000 : "java" 0x000004280000-0x00000a280000 : "yaffs" 0x00000de40000-0x00000e000000 : "reservearea" rootfs PPP generic driver version 2.4.2 PPP Deflate Compression module registered PPP BSD Compression module registered kworker/u:0 used greatest stack depth: 15208 bytes left kworker/u:0 used greatest stack depth: 15080 bytes left cryptomgr_probe used greatest stack depth: 14808 bytes left PPP MPPE Compression module registered NET: Registered protocol family 24 RT3xxx EHCI/OHCI init. usbcore: registered new interface driver cdc_acm cdc_acm: v0.26:USB Abstract Control Model driver for USB modems and ISDN adapters usbcore: registered new interface driver usbserial USB Serial support registered for generic usbcore: registered new interface driver usbserial_generic usbserial: USB Serial Driver core USB Serial support registered for ch341-uart usbcore: registered new interface driver ch341 USB Serial support registered for cp210x usbcore: registered new interface driver cp210x cp210x: v0.09:Silicon Labs CP210x RS232 serial adaptor driver USB Serial support registered for DeLorme Earthmate USB USB Serial support registered for HID->COM RS232 Adapter USB Serial support registered for Nokia CA-42 V2 Adapter usbcore: registered new interface driver cypress cypress_m8: v1.10:Cypress USB to Serial Driver USB Serial support registered for FTDI USB Serial Device usbcore: registered new interface driver ftdi_sio ftdi_sio: v1.6.0:USB FTDI Serial Converters Driver USB Serial support registered for pl2303 usbcore: registered new interface driver pl2303 pl2303: Prolific PL2303 USB to serial adaptor driver usbcore: registered new interface driver hiddev usbcore: registered new interface driver usbhid usbhid: USB HID core driver Netfilter messages via NETLINK v0.30. nf_conntrack version 0.5.0 (3959 buckets, 15836 max) ctnetlink v0.93: registering with nfnetlink. nf_conntrack_rtsp v0.6.21 loading nf_nat_rtsp v0.6.21 loading ip_tables: (C) 2000-2006 Netfilter Core Team TCP cubic registered NET: Registered protocol family 10 ip6_tables: (C) 2000-2006 Netfilter Core Team IPv6 over IPv4 tunneling driver NET: Registered protocol family 17 802.1Q VLAN Support v1.8 Ben Greear <greearb@candelatech.com> All bugs added by David S. Miller <davem@redhat.com> VFS: Mounted root (squashfs filesystem) readonly on device 31:3. Freeing unused kernel memory: 220k freed busybox init and set aff init started: BusyBox v1.00 (2019.03.11-03:10+0000) multi-call binary [ used greatest stack depth: 14168 bytes left chmod: /userfs/profile.cfg: Read-only file system Ebtables v2.0 registered insmod used greatest stack depth: 13936 bytes left mtd[readflash]:device=reservearea tclen=262144 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/prolinecwmppararead ... 00000000h: 04 BD 07 14 06 19 01 87 FF FF FF FF 4C 48 00 AA 00000010h: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 00000020h: 00 24 00 14 FF FF FF FF FF FF FF FF 00 00 00 01 00000030h: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 00000040h: 00 AC 61 84 FF FF FF FF FF FF FF FF FF FF FF FF 00000050h: 27 10 0D 00 03 E8 01 40 00 64 00 1F FF FF FF FF 00000060h: FF FF FF FF 00 06 00 20 FF FF FF FF FF FF FF FF 00000070h: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 00000080h: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 00000090h: FF FF FF FF 07 05 07 01 FF FF FF FF FF FF FF FF 000000a0h: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 000000b0h: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 000000c0h: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 000000d0h: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF 000000e0h: 00insmod: cannot open module `/lib/modules/maxnetdpi.ko': No such file or directory insmod: cannot open module `/lib/modules/tcfullcone.ko': No such file or directory module_sel: module license 'unspecified' taints kernel. Disabling lock debugging due to kernel taint 7512 chip select cat: /proc/tc3162/sys_chip_type: No such file or directory error chip id BusyBox v1.00 (2019.03.11-03:10+0000) multi-call binary Usage: cp [OPTION]... SOURCE DEST vtag_drv_init insmod used greatest stack depth: 13912 bytes left tcsmux version: tcsmux V1.1.0.0 (Feb 27 2019-11:49:22). tcportbind version: tcportbind V1.1.0.0 (Aug 30 2017-20:09:16). TCSUPPORT_IPV6 [: ==: unknown operand tcaccesslimit version: accesslimit V1.2.0.0 (May 28 2017-15:05:00). url_filter_init TC3162 LED Manager 0.1 init tcledctrl version: tcledctrl V1.1.0.0 (Mar 7 2019-17:44:30). led path:/userfs/led.conf tccicmd V1.1.0.0 (Mar 7 2019-17:44:32) SIFMaster 0.1 init Register sifm cmd [: ==: unknown operand [: ==: unknown operand insmod ETH_LAN driver macType = 0 qdma_lan: physical_size is 0x00200000 ether.c:v1.00-NAPI 29.Mar.2015 eth0: FE MAC Ethernet address: 58:C8:76:FB:9B:F0 Use Internal switch ,type 10 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 9414 7522 Fe, [tcPhyInit] in [tcPhyInit] out , r31 = (9, 0xb000) tcPhyVerLookUp 4014 9414 7522 Fe, [tcPhyInit] in [tcPhyInit] out , r31 = (10, 0xb000) tcPhyVerLookUp 4014 9414 7522 Fe, [tcPhyInit] in [tcPhyInit] out , r31 = (11, 0xb000) tcPhyVerLookUp 4014 9471 7522 Ge, [tcPhyInit] in [tcPhyInit] out , r31 = (12, 0x0) tcPhyVerLookUp 4014 9471 7522 Ge, [tcPhyInit] in [tcPhyInit] out , r31 = (12, 0x0) GE Rxet cal (1)(0)(0)(0x21) GE Rext AnaCal Done! (2)(0x22) GE Rext AnaCal Done! (2)(0x22) GE R50 AnaCal Done! (4) (0x25)(0xa5) GE R50 AnaCal Done! (2) (0x27)(0xa7) GE R50 AnaCal Done! (3) (0x26)(0xa6) GE-c zcal(38) GE R50 AnaCal Done! (3) (0x26)(0xa6) GE-d zcal(38) GE Tx offset AnaCal Done! (5)(0x25) GE Tx offset AnaCal Done! (6)(0x26) GE Tx offset AnaCal Done! (4)(0x24) GE Tx offset AnaCal Done! (1)(0x21) GE-a tx_amp(24) GE Tx amp AnaCal Done! (pair-0)(0x12)(0x7420) GE Tx amp AnaCal Done! (8) (0x18) GE-b tx_amp(17) GE Tx amp AnaCal Done! (pair-1)(0x17)(0x1720) GE Tx amp AnaCal Done! (15) (0x11) GE-c,d tx_amp(13) GE Tx amp AnaCal Done! (pair-2)(0x19)(0x1620) GE Tx amp AnaCal Done! (19) (0xd) GE-c,d tx_amp(21) GE Tx amp AnaCal Done! (pair-3)(0x21)(0x1e20) GE Tx amp AnaCal Done! (11) (0x15) tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 0 tcPhyVerLookUp 4014 9414 7522 Fe, FE-9 R50 AnaCal Done! (2)(0x1e) 7522 FE zcal tx(42) rx(39) 7522 FE l4_22(0x2a00) 7522 FE l4_22(0x2a27) FE-9 Tx offset AnaCal Done! (9)(7)(0x7) FE-9 Tx amp AnaCal Done! (1)(0xf) FE-9 Tx amp AnaCal Done! (1)(0xf) tcPhyVerLookUp 4014 9414 7522 Fe, FE-10 R50 AnaCal Done! (3)(0x1d) 7522 FE zcal tx(45) rx(41) 7522 FE l4_22(0x2d00) 7522 FE l4_22(0x2d29) FE-10 Tx offset AnaCal Done! (5)(3)(0x3) FE-10 Tx amp AnaCal Done! (1)(0xf) FE-10 Tx amp AnaCal Done! (1)(0xf) tcPhyVerLookUp 4014 9414 7522 Fe, FE-11 R50 AnaCal Done! (3)(0x1d) 7522 FE zcal tx(40) rx(40) 7522 FE l4_22(0x2800) 7522 FE l4_22(0x2828) FE-11 Tx offset AnaCal Done! (3)(-1)(0x21) FE-11 Tx amp AnaCal Done! (2)(0x14) FE-11 Tx amp AnaCal Done! (2)(0x14) tcPhyVerLookUp 4014 9471 7522 Ge, the number of cfg node is 120 eth0: starting interface. netif_start_queue cwmpRoute_init autopvc_init netif_stop_queue [wpsStatusUpdate]:ioctl open fail ctromfile.cfg ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail mtd[readflash]:device=reservearea tclen=2248 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/productlinecwmpfile ... Exec. Successful Exec. Successful Exec. Successful * Phyaddr=1 RegAddr=09 value=1400 * Phyaddr=2 RegAddr=09 value=1400 * Phyaddr=3 RegAddr=09 value=1400 ctromfile.cfg eth0: starting interface. netif_start_queue TCSUPPORT_USBHOST SCSI subsystem initialized verify_romfile func: None PppoeEmulatorBridge node, will get it from default romfile verify_roverify_romfile func: None PppoeEmulatorBridge node from default romfile mfile func: Nerify_romfile func: None AttachWanDNSTunnel node, will get it from default romfile one Pppoverify_romfile func: None AttachWanDNSTunnel node from default romfile eEmulatorBrverify_romfile func: None DnsSpeedLimit node, will get it from default romfile idge nodverify_romfile func: None DnsSpeedLimit node from default romfile e, will geverify_romfile func: None MaxBandWidth node, will get it from default romfile t it froverify_romfile func: None MaxBandWidth node from default romfile m default romfile ververify_romfile func: None WlanShare node, will get it from default romfile ify_romverify_romfile func: None WlanShare node from default romfile file func: None PppoeEmulatorBridge node from default romfile versslca_verify! ify_romfile func: None AttachWanDNSTunnel node, will get it from default romfile verify_romfile func: None AttachWanDNSTunnel node from default romfile verify_romfile func: None DnsSpeedLimit node, will get it from default romfile verify_romfile func: None DnsSpeedLimit node from default romfile verify_romfile func: None MaxBandWidth node, will get it from default romfile verify_romfile func: None MaxBandWidth node from default romfile verify_romfile func: None WlanShare node, will get it from default romfile verify_romfile func: None WlanShare node from default romfile Check romfile pass! mtd[readflash]:device=reservearea tclen=262144 tcoffset=0 Unlocking reservearea ... Reading from reservearea to /tmp/tc_backupromfile ... [BK_ROMFILE_FLAG]/userfs/bin/mtd readflash /tmp/tc_backupromfile 262144 0 reservearea insmod: cannot open module `/lib/modules/usbhost/nls_base.ko': No such file or directory [wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ctromfile.cfg ==>getMacEntryByIndex(): ioctl open fainsmod used greatest stack depth: 13616 bytes left il ==>getMacEntryByIndex(): ioctl open fail insmod: cannot open module `/lib/modules/usbhost/fat.ko': No such file or directory insmod: cannot open module `/lib/modules/usbhost/vfat.ko': No such file or directory insmod: cannot open module `/lib/modules/usbhost/usbcore.ko': No such file or directory 7522 USB PHY config, enable port0 USB driver version: 751221.2.20160516 port 0 u2_slew_rate_calibration mtd[readflash]:device=reservearea tclen=2248 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/productlinecwmpfile ... FM_OUT value = 144(0x00000090) SR calibration value = 4 port 1 u2_slew_rate_calibration ctromfile.cfg FM_OUT value = 144(0x00000090) SR calibration value = 4 verify_romfile func: None PppoeEmulatorBridge node, will get it from default romfile verify_rverify_romfile func: None PppoeEmulatorBridge node from default romfile omfile func: verify_romfile func: None AttachWanDNSTunnel node, will get it from default romfile None Pppverify_romfile func: None AttachWanDNSTunnel node from default romfile oeEmulatorverify_romfile func: None DnsSpeedLimit node, will get it from default romfile Bridge nverify_romfile func: None DnsSpeedLimit node from default romfile ode, will verify_romfile func: None MaxBandWidth node, will get it from default romfile get it ferify_romfile func: None MaxBandWidth node from default romfile rom default romfile verify_romfile func: None WlanShare node, will get it from default romfile verify_rverify_romfile func: None WlanShare node from default romfile omfile func: None PppoeEmulatorBridge node from default romfile sslca_verify! verify_romfile func: None AttachWanDNSTunnel node, will get it from default romfile verify_romfile func: None AttachWanDNSTunnel node from default romfile verify_romfile func: None DnsSpeedLimit node, will get it from default romfile verify_romfile fuxhc_mtk xhc_mtk: xHCI Host Controller nxhc_mtk xhc_mtk: new USB bus registered, assigned bus number 1 c: None DnsSpeedLimit node from default romfile verify_romfile func: None MaxBandWidth node, will get it from default romfile verify_romfile func: None MaxBandWidth node from default romfile verify_romfile func: None WlanShare node, will get it from default romfile verify_romfile func: None WlanShare node from default romfile xhc_mtk xhc_mtk: irq 18, io mem 0x1fb90000 hub 1-0:1.0: USB hub found hub 1-0:1.0: 1 port detected xhc_mtk xhc_mtk: xHCI Host Controller xhc_mtk xhc_mtk: new USB bus registered, assigned bus number 2 hub 2-0:1.0: USB hub found hub 2-0:1.0: 1 port detected insmod used greatest stack depth: 13296 bytes left dhcp6sCall_write:mode[0]=0 [create_route_sh:3526] Initializing USB Mass Storage driver... usbcore: registered new interface driver usb-storage USB Mass Storage support registered. killall: phddns: no process killed Attribute username not fetch value! fuse init (API version 7.15) [wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail mtd[readflash]:device=romfile tclen=65536 tcoffset=0 Unlocking romfile ... Reading from romfile to /tmp/var/romfile.cfg~~ ... ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail insmod: cannot open module `/lib/modules/usbhost/nls_utf8.ko': No such file or directory macType = 0 qdma_wan: qdma_bmgr.c [2814]: HW_FWD physical size is not illegal, force setting to 4MB qdma_wan: physical_size is 0x00400000 Using intrapositioned negation (`--option ! this`) is deprecated in favor of extrapositioned (`! --option this`). iptables v1.4.10: can't initialize iptables table `filter': Table does not exist (do you need to insmod?) Perhaps iptables or your kernel needs to be upgraded. Exec. Successful Exec. Successful Exec. Successful iptables v1.4.10: can't initialize iptables table `filter': Table does not exist (do you need to insmod?) Perhaps iptables or your kernel needs to be upgraded. EN7571 found! Using FLASH matrix got intrapositioned negation (`--option ! this`) is deprecated in favor of extrapositioned (`! --option this`). PWRADC offset = 0x3f4b PWRADC ready BG 1.76V = 0x29b BG 0.875V = 0x150 RSSI_Vref = 0x222 RSSI_V = 0x2a1 eFuse value = 0xa eFuse offset = 3.0'C Start GPON Tx Calibration RGS_T0C = 0x48 RGS_T1C = 0x4c APD initialization done Initial current loaded PWR/ER loaded TIASD = 0x37 Rx LOS is set Internal DDMI Enabled KT Enabled EN7571 Initialization Done! iptables v1.4.10: can't initialize iptables table `filter': Table does not exPON PHY driver version is 170228.105.8 ist (do you need to insmod?) Perhaps iptables or your kernel needs to be upgraded. [wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryB FtpEntry0 is deactive!!yInd FtpEntry1 is deactive!!ex() FtpEntry2 is deactive!!: io FtpEntry3 is deactive!!ctl open fail FtpEntry4 is deactive!! FtpEntry5 is deactive!! Attribute username not fetch value!Using intrapositioned negation (`--option ! this`) is deprecated in favor of extrapositioned (`! --option this`). xPON driver initialization Alloc data struct memory successful, 35468 iptables v1.4.10: can't initialize iptables table `filter': Table does not exist (do you need to insmod?) Perhaps iptables or your kernel needs to be upgraded. XPON Mapping Module init OK! insmod: cannot open module `/lib/modules/brg_shortcut.ko': No such file or directory iptables v1.4.10: can't initialize iptables table `filter': Table does not exist (do you need to insmod?) Perhaps iptables or your kernel needs to be upgraded. init traffic_classify. Using intrapositioned negation (`--option ! this`) is deprecated in favor of extrapositioned (`! --option this`). iptables v1.4.10: can't initialize iptables table `filter': Table does not exist (do you need to insmod?) Perhaps iptables or your kernel needs to be upgraded. wlanshare: wlanshare_init ok Attribute username not fetch value!func speed_test_ctrl_itf_init line 1319 func speed_test_ctrl_itf_init line 1328 func speed_test_ctrl_itf_init line 1338 ConsoleEntry not found!ip=0.0.0.0 ip=0.0.0.0 acl_cmd=iptables -t filter -A acl_chain -i br0 -p TCP -m multiport --dport ftp,telnet,http,snmp -m iprange --src-range 0.0.0.0-223.255.255.255 -j ACCEPT acl_cmd=iptables -t filter -A acl_chain -i br0 -p UDP -m multiport --dport ftp,telnet,http,snmp -m iprange --src-range 0.0.0.0-223.255.255.255 -j ACCEPT acl_cmd=iptables -t filter -A acl_chain -i br0 -p ICMP --icmp-type 8 -m iprange --src-range 0.0.0.0-223.255.255.255 -j ACCEPT [Simulate Test] line_simulate_test_write [Simulate Test] line_simulate_test_write [0] not supported! sslca_write:get Frag Number failed! dms:get new Lan ipaddr 192.168.1.1 ntry0 Active not fetch value or No! ntry1 Active not fetch value or No! ntry2 Active not fetch value or No! ntry3 Active not fetch value or No! ntry4 Active not fetch value or No! ntry5 Active not fetch value or No![wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail insmod: cannot open module `/lib/modules/mldsnooping.ko': No such file or directory ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail The remaining IMEM space cannot accommodate section .imem_text !! Remaining IMEM space: 7204 bytes Section Size: 9056 bytes HWNAT Module enabled with Type:L2B/IPv4/IPv6/DS-LITE/6RD, foeSize:80B, foeNum:16384 IP check use Black List start blockProcess===============> [wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail blockProcess is processing!!!=========> blockProcess is processing!!!=========> [wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail blockProcess is processing!!!=========> [wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail killall: xl2tpd: no process killed Chain 'vpn_lan_entry0' doesn't exist. Chain 'vpn_lan_entry0' doesn't exist. blockProcess is processing!!!=========> iptables: No chain/target/match by that name. iptables v1.4.10: can't initialize iptables table `filter': Table does not exist (do you need to insmod?) Perhaps iptables or your kernel needs to be upgraded. apiPermission_configure[7760]:Fail to open apifile =/usr/osgi/plugin-b/com.chinamobile.smartgateway.appcore.policy apiPermission_configure[7760]:Fail to open apifile =/usr/osgi/plugin-b/com.chinamobile.smartgateway.cmccdpi.policy apiPermission_configure[7760]:Fail to open apifile =/usr/osgi/plugin-b/com.chinamobile.smartgateway.andlink.policy [wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail Can't open /etc/Wireless/WLAN_APOn File /etc/Wireless/RT2860AP/RT2860AP.dat content HT_BSSCoexistence= is worng mtd[readflash]:device=reservearea tclen=2248 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/productlinecwmpfile ... lanHost_read: Create node LanHost ! Cannot find device "br0" Wrong dispBytes dynCwmpAttr_read: wlanflag.magic is wrong now is [0000] should be [22335566]! Idx invalid param, pvcNum is -1, entryNum is -1 access.c====>addDisInf/8794 stat fail! usbmount_readret:-1 get UsbMount_Entry0 failaccess.c====>addDisInf/8794 stat fail! usbmount_readret:-1 get UsbMount_Entry1 failCannot find device "br0" signalBlockProcess===========> Killed needAsynchronous =1,gettid()=145!!! exec_service_init init ok[exec_service_proc:124]gettid()=495,pthread_self()=762311840, getpid()=145 device eth0 entered promiscuous mode TCSUPPORT_CT_NETWORKMANAGESERVICE:no need to start utelnetd up in rcs! TCSUPPORT_CT_NETWORKMANAGESERVICE:no need to use inetd! TCSUPPORT_CT:no need to use tftpd! [wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail TC3162 hardware watchdog initialized ==>getMacEntryByIndex(): ioctl open fail four ports ==>getMacEntryByIndex(): ioctl open fail device eth0.1 is not a slave of br0 device eth0.2 is not a slave of br0 device eth0.3 is not a slave of br0 device eth0.4 is not a slave of br0 device eth0 is already a member of a bridge; can't enslave it to bridge br0. device eth0.1 entered promiscuous mode [wpsStatusUpdate]:ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail device eth0.2 entered promiscuous mode ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail device eth0.3 entered promiscuous mode device eth0.4 entered promiscuous mode device eth0 left promiscuous mode br0: port 1(eth0) entering disabled state [01/Jan/1970:00:00:23 +0000] boa: server version Boa/0.94.13 [01/Jan/1970:00:00:23 +0000] boa: server built Mar 11 2019 at 11:16:21. [01/Jan/1970:00:00:23 +0000] boa: starting server pid=533, port 80 ==>Syslog Error, write logMsg, open file /var/log/currLogFile failed Sys_boot 14136:Zone=GV Sys_boot 14164:currversion=V2.5.3 Sys_boot 14186:ManufacturerSWVersion=HY_02_MC_3GV_19_03_11_074 Sys_boot 14197:curSWDate=2019-03-11 11:31:48 !!! mtd[readflash]:device=reservearea tclen=1 tcoffset=1572864 Unlocking reservearea ... Reading from reservearea to /tmp/dual_image_boot_flag ... mtd[readflash]:device=reservearea tclen=2248 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/productlinecwmpfile ... ifconfig: ra0: error fetching interface information: Device not found ra0 no private ioctls. ifconfig: ra0: error fetching interface information: Device not found no voice link Send OAM Update config! !sendEponOamCmdMsg open message queue fail! [wpsStatusUpdate]:ioctl open fail ctromfile.cfg Unlocking romfile ... Writing from /tmp/tc_store_romfile.conf to romfile ... [ ][e][w]not Error writing tclinux,mtd=romfile. Unlocking reservearea ... Erase one sector from 0x0 of reservearea ... tcoffset:0x0,mtdInfo.size:0x1c0000 size-1:1ffff enter real action ----- tcoffset:0x0 [e]mtd[writeflash]:device=reservearea tclen=262144 tcoffset=0 tcfilelen =11986 Unlocking reservearea ... Writing from /tmp/tc_store_romfile.conf to reservearea ... enter real action -----tclen:0x40000,tcoffset:0x0 writeflash: write 0 'st sector,start from 0x0,0x20000 bytes [e][w]enter real action -----tclen:0x20000,tcoffset:0x20000 writeflash: write 1 'st sector,start from 0x20000,0x20000 bytes read:count <= 0 writeflash: total write 0x2ed2 bytes wan_boot 1970:wan_boot start !!! 00:00:25 imgr.c [71]: Initial system driver. 00:00:25 imgr.c [77]: Initial pthread parameters. 00:00:25 imgr.c [83]: Initial dispatcher. 00:00:25 dspch_init.c [23]: Create IPC trap message queue 00:00:25 dspch_init.c [36]: Create IPC trap message queue 00:00:25 imgr.c [89]: Initial database manager. 00:00:25 dbmgr_init.c [32]: Crea ywd:omci start at wan_boot te database memory. 00:00:25 dbmgr_init.c [38]: Create the share database memory successful. 00:00:25 dbmgr_init.c [41]: The total share database size is 0. 00:00:25 imgr.c [95]: Initial config manager. 00:00:25 imgr.c [101]: Initial fault manager. 00:00:25 imgr.c [107]: Initial performance manager. sh: cannot create /proc/tc3162/eth_ports: Directory nonexistent br0: port 5(eth0.4) entering forwarding state br0: port 5(eth0.4) entering forwarding state br0: port 4(eth0.3) entering forwarding state br0: port 4(eth0.3) entering forwarding state br0: port 3(eth0.2) entering forwarding state br0: port 3(eth0.2) entering forwarding state br0: port 2(eth0.1) entering forwarding state br0: port 2(eth0.1) entering forwarding state accesslimitcmd used greatest stack depth: 13136 bytes left SIOCSIFADDR: File exists done method = HW_NAT_TAB_CLEAN done Radvd function activated! Mode:Dhcp6s mode is not manual! killall: udhcpd: no process killed radvd starting sh: /userfs/bin/dproxy: not found voip_real_execute in VoIPBasic_Common SIPProtocol is IMSSIP udhcpd (v0.9.9-pre) started ==>getMacEntryByIndex(): ioctl open fail TCSysLog udhcpd[803]: udhcpd (v0.9.9-pre) started Unable to open /etc/udhcpd.leases for reading TCSysLog udhcpd[803]: Unable to open /etc/udhcpd.leases for reading ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ct com valid subcommands: adsl set olt type: 0 echo used greatest stack depth: 7856 bytes left mtd[readflash]:device=reservearea tclen=2248 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/productlinecwmpfile ... File /etc/deviceParaStatic.conf content SVNURL= is worng File /etc/deviceParaWPSActiveStatus = NULL Static.conf content Lanports= is worng pon_vlan_init Multi Lan portWPSOOBActive = NULL WPSGenPinCode = NULL initilize xpon igmp module....done! pon_mac_filter_init Multi Lan portmtd[readflash]:device=reservearea tclen=512 tcoffset=1310720 Unlocking reservearea ... Reading from reservearea to /tmp/RT30xxEEPROM.bin ... ra0 no private ioctls. read WLAN driver from rt_device failed,set with default value! killall: wscd: no process killed ========================insmod iptable_filter======================= chmod: /userfs/profile.cfg: Read-only file system TCSUPPORT_WLAN TCSUPPORT_WLAN_MT7592 ftp switch turn on sip switch turn on h323 switch turn on rtsp switch turn on l2tp switch turn on,sw_state= iptables: Bad rule (does a matching rule exist in that chain?). ipsec switch turn on,sw_state= iptables: Bad rule (does a matching rule exist in that chain?). pptp switch turn on mtd[readflash]:device=reservearea tclen=2248 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/productlinecwmpfile ... File /etc/deviceParaStatic.conf content SVNURL= is worng File /etc/deviceParaStatic.conf content Lanports= is worng [wpsStatusUpdate]:ioctl open fail mtd[readflash]:device=reservearea tclen=2248 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/productlinecwmpfile ... File /etc/deviceParaStatic.conf content SVNURL= is worng File /etc/deviceParaStatic.conf content Lanports= is worng ifconfig: ra0: error fetching interface information: Device not found ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ==>getMacEntryByIndex(): ioctl open fail ra0 no private ioctls. ifconfig: ra0: error fetching interface information: Device not found ==>Syslog Err Send OAM Update config! !or, write logMsg, open file /var/log/currLogFile failed ctromfile.cfg register mt_drv PCI: Enabling device 0000:01:00.0 (0000 -> 0002) === pAd = c1702000, size = 806000 === <-- RTMPAllocTxRxRingMemory, Status=0, ErrorValue=0x <-- RTMPAllocAdapterBlock, Status=0 pAd->CSRBaseAddress =0xc1600000, csr_addr=0xc1600000! device_id =0x7603 RtmpChipOpsHook(507): Not support for HIF_MT yet! mt7603_init()--> mt_bcn_buf_init(224): Not support for HIF_MT yet! <--mt7603_init() TCSUPPORT_WLAN: ifconfig Unlocking romfile ... Writing from /tmp/tc_store_romfile.conf to romfile ... [ ][e][w]not Error writing tclinux,mtd=romfile. TX_BCN DESC ab195000 size = 320 RX[0] DESC ab197000 size = 2048 RX[1] DESC ab198000 size = 2048 Unlocking reservearea ... Erase one sector from 0x0 of reservearea ... tcoffset:0x0,mtdInfo.size:0x1c0000 size-1:1ffff enter real action ----- tcoffset:0cfg_mode=9 cfg_mode=9 wmode_band_equal(): Band Equal! x0 [e]mtd[writeflash]:device=reservearea tclen=262144 tcoffset=0 tcfilelen =11989 Unlocking reservearea ... Writing from /tmp/tc_store_romfile.conf to reservearea ... enter real action -----tclen:0x40000,tcoffset:0x0 writeflash: write 0 'st sector,start from 0x0,0x20000 bytes [e][w]enter real action -----tclen:0x20000,tcoffset:0x20000 writeflash: write 1 'st sector,start from 0x20000,0x20000 bytes read:count <= 0 writeflash: total write 0x2ed5 bytes valid subcommands: adsl Enter cwmp boot, we will start tr69 Process Key1Str is Invalid key length(1) or Type(0) Key1Str is Invalid key length(1) or Type(0) Key1Str is Invalid key length(1) or Type(0) Key1Str is Invalid key length(1) or Type(0) Key2Str is Invalid key length(1) or Type(0) Key2Str is Invalid key length(1) or Type(0) Key2Str is Invalid key length(1) or Type(0) Key2Str is Invalid key length(1) or Type(0) Key3Str is Invalid key length(1) or Type(0) Key3Str is Invalid key length(1) or Type(0) Key3Str is Invalid key length(1) or Type(0) Key3Str is Invalid key length(1) or Type(0) Key4Str is Invalid key length(1) or Type(0) Key4Str is Invalid key length(1) or Type(0) Key4Str is Invalid key length(1) or Type(0) Key4Str is Invalid key length(1) or Type(0) PS_RETRIEVE = 1 FW Version:ap_pcie FW Build Date:20160107100755 CmdAddressLenReq:(ret = 0) CmdFwStartReq: override = 1, address = 1048576 CmdStartDLRsp: WiFI FW Download Success AsicDMASchedulerInit(): DMA Scheduler Mode=0(LMAC) efuse_probe: efuse = 10000002 RtmpChipOpsEepromHook::e2p_type=4, inf_Type=5 RtmpEepromGetDefault::e2p_dafault=1 RtmpChipOpsEepromHook: E2P type(4), E2pAccessMode = 4, E2P default = 1 NVM is BIN mode 1. Phy Mode = 14 Cal Free IC!! @@@ NICReadEEPROMParameters : pAd->FWLoad=0 Certificate file isn't exist! now bb MainSsid mac 58:c8:76:fb:9b:f0 Country Region from e2p = ffff tssi_1_target_pwr_g_band = 32 2. Phy Mode = 14 3. Phy Mode = 14 NICInitPwrPinCfg(14): Not support for HIF_MT yet! NICInitializeAsic(585): Not support rtmp_mac_sys_reset () for HIF_MT yet! mt_mac_init()--> mt7603_init_mac_cr()--> AsicSetMacMaxLen(1826): Set the Max RxPktLen=1024! <--mt_mac_init() WTBL Segment 1 info: MemBaseAddr/FID:0x28000/0 EntrySize/Cnt:32/128 WTBL Segment 2 info: MemBaseAddr/FID:0x40000/0 EntrySize/Cnt:64/128 WTBL Segment 3 info: MemBaseAddr/FID:0x42000/64 EntrySize/Cnt:64/128 WTBL Segment 4 info: MemBaseAddr/FID:0x44000/128 EntrySize/Cnt:32/128 MtAsicACQueue: Write CR:21510, Value=10421 MtAsicACQueue: Write CR:21500, Value=10421 mAntCfgInit(2593): Not support for HIF_MT yet! tRTMPSetPhyMode(): channel out of range, use first ch=0 d[MCS Set = ff ff 00 00 00 readflash]:device=reservearea tclen=2248 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/productlinecwmpfile ... File /etc/deviceParaStatic.conf content SVNURL= is worng File /etc/deviceParaStatic.conf content Lanports= is worng mtd[readflash]:device=reservearea tclen=2248 tcoffset=786432 Unlocking reservearea ... Reading from reservearea to /tmp/productlinecwmpfile ... File /etc/deviceParaStatic.conf content SVNURL= is worng File /etc/deviceParaStatic.conf content Lanports= is worng Please press Enter to activate this console. sendOmciCmdMsg open message queue fail! Send OAM Update config! ! Attribute username not fetch value! Attribute username not fetch value!AsicSetRalinkBurstMode(4155): Not support for HIF_MT yet! RTMPSetPiggyBack(876): Not support for HIF_MT yet! AsicSetTxPreamble(4142): Not support for HIF_MT yet! AsicAddSharedKeyEntry(1992): Not support for HIF_MT yet! AsicAddSharedKeyEntry(1992): Not support for HIF_MT yet! AsicAddSharedKeyEntry(1992): Not support for HIF_MT yet! AsicAddSharedKeyEntry(1992): Not support for HIF_MT yet! AsicSetPreTbtt(): bss_idx=0, PreTBTT timeout = 0xa0 Main bssid = 58:c8:76:fb:9b:f0 <==== rt28xx_init, Status=0 @@@ ed_monitor_exit : ===> @@@ ed_monitor_exit : <=== mt7603_set_ed_cca: TURN OFF EDCCA mac 0x10618 = 0xd7083f0f, EDCCA_Status=0 jiffies=ffff987a, POLLING_MODE_DETECT_INTV=300 WiFi Startup Cost (ra0): 4.030s device ra0 entered promiscuous mode br0: port 1(ra0) entering forwarding state br0: port 1(ra0) entering forwarding state ##### mbss_cr_enable, BssId = 1 device ra1 entered promiscuous mode updateDevBandWidthMac:index=0,5a:c8:76:db:9b:f0 br0: port 6(ra1) entering forwarding state br0: port 6(ra1) entering forwarding state br0: port 6(ra1) entering forwarding state ##### mbss_cr_enable, BssId = 2 device ra2 entered promiscuous mode updateDevBandWidthMac:index=1,5a:c8:76:eb:9b:f0 br0: port 7(ra2) entering forwarding state br0: port 7(ra2) entering forwarding state br0: port 7(ra2) entering forwarding state ##### mbss_cr_enable, BssId = 3 device ra3 entered promiscuous mode updateDevBandWidthMac:index=2,5a:c8:76:fb:9b:f0 br0: port 8(ra3) entering forwarding state br0: port 8(ra3) entering forwarding state br0: port 8(ra3) entering forwarding state device registration webpage UNLOCKED! parameter_init(), conReqDelay = parameter_init(), multiConReq = parameter_init(), itmsRebootFlag = ==> EPON OAM Start need 10s:355152us VoIPBasic_Common SIPProtocol is IMSSIP voip_basic_boot: prevSipStatus is 0 connect fail! connect fail! tr069 tcapi mode is 1 ThreadedTimerCheck: get last for first time connect fail! connect fail! bw = 0enable=1,8d5283780000,actionType=0 enable=1,8d5288580000,actionType=0 apiPermission_configure[7760]:Fail to open apifile =/usr/osgi/plugin-b/com.chinamobile.smartgateway.appcore.policy apiPermission_configure[7760]:Fail to open apifile =/usr/osgi/plugin-b/com.chinamobile.smartgateway.cmccdpi.policy apiPermission_configure[7760]:Fail to open apifile =/usr/osgi/plugin-b/com.chinamobile.smartgateway.andlink.policy cmcc starting up... main 79:Zone=GV qos_boot: init app mode for boot [TR069,VOIP,IPTV,INTERNET] XPON ONU login:

COPY HERE THE BOOTLOG ONCE OPENWRT IS INSTALLED AND RUNNING
